Module: P10 DIP 32*32 (4 PCS)
Pixel pitch: 10mm
Pixel composition: 1R 1G 1B
Module Size (W *L)mm: 320 x 320
Module Size (W * L) Pixel: 32x 32
Cabinet Size (W*L* H)mm: 640 X 640*120
Cabinet Resolution (W *L)pixels: 64 X 64
$907.20
60 in stock
< Free of DHL shipping >
|
Module
|
P10 DIP 32*32 (4 PCS)
|
|
Pixel pitch
|
10mm
|
|
Pixel composition
|
1R 1G 1B
|
|
Module Size (W *L)mm
|
320 x 320
|
|
Module Size (W * L) Pixel
|
32x 32
|
|
Cabinet Size (W*L* H)mm
|
640 X 640*120
|
|
Cabinet Resolution (W *L)pixels
|
64 X 64
|
|
Display Screen
|
|
|
Color
|
16,384 grey grades, totally 4,398 x 109M colors
|
|
Weight per cabinet
|
17KG
|
|
Max brightness(CD/m²)
|
≥6,500
|
|
Power consumption(Max)
|
300W
|
|
Power consumption(average)
|
120W
|
|
Power supply
|
88-132VAC/ 176-264VAC selected by switch
|
|
Viewing distance (Meter)
|
10 – 200
|
|
Brightness adjustment
|
256 grades adjust
|
|
Viewing angle
|
horizontal≥110°vertical:up≥15°down≥30°
|
|
Refresh Frame Frequency
|
>120 frames/second
|
|
Refresh Ration
|
>240HZ
|
|
Continuous work time
|
>24 hrs
|
|
Life time
|
>100,000Hrs
|
|
Operating temperature
|
-20°C ~ +60°C
|
|
Operating humidity
|
10% ~ 90%RH
|
|
Waterproof standard
|
IP65
|
|
Linsn Control system
|
|
|
Control method
|
Synchronous control with PC, instance display,
|
|
Included Linsn or Novastar receiver card
|
|
|
Video input
|
DVI, Composite video, RGE, VGA,S-Video
|
|
Brightness control
|
Program control or manual control available
|
|
Gamma correction
|
Yes
|
No include sending card. ( delivery in 15 days after you paid. )
| Weight | 18 kg |
|---|
